HME NEXEO | HDX Drive-Thru Speaker (SS7000)
HME NEXEO | HDX Drive-Thru Speaker (SS7000)
SKU:G30261-1A1
Couldn't load pickup availability
Keep it covered with a Protection Plan One monthly price for repairs, and a spare ships first when something fails.
Not sure this fits your system?Call or text a TechChefs tech at 972-901-9948 or email us the model number. We will confirm before you order.
- Genuine OEM part
- Ships from Texas
- Real tech support
The HME SS7000 is the outdoor drive-thru speaker designed for the NEXEO | HDX platform. It delivers clear guest audio at the post and is powered from the BS7000 base station.
- NEXEO | HDX SpeakerPurpose-built outdoor speaker for the NEXEO platform.
- 15 W / 8 ohmSized for menu-board and speaker-post installs.
- Powered from BS700048 VDC from the NEXEO | HDX base station.
- Wide Audio Band100 Hz to 7.4 kHz to match HDX digital audio.
- Weather RatedOperating range -25 to 60 C (-13 to 140 F).
Platform notes
- HDX Guest Audio
- The SS7000 is tuned for the same wideband path as NEXEO headsets so guests hear natural, clear speech.
- Mic Pairing
- Use a DM5 microphone for guest talkback on NEXEO | HDX.
Specifications
Speaker
| Model | SS7000 |
|---|---|
| Power | 15 W |
| Impedance | 8 ohm |
| Power Supply | 48 VDC from BS7000 |
| Audio Frequency Range | 100 Hz to 7.4 kHz |
| Dimensions | 3.92 in H x 5.76 in W x 3.44 in D (99.6 x 146.3 x 87.4 mm) |
| Weight | 1.14 lb (492.6 g) |
| Connections | Phoenix connector headers |
| Operating Temperature | -25 to 60 C (-13 to 140 F) |
Specs from HME NEXEO | HDX data sheet PUB-00144 Rev F. Sold and supported by TechChefs, an authorized HME dealer. Call or text 972-901-9948 if you need help matching a part to your system.
