Luminys N9 2 x 4MP Unstitched Dome 2.8 mm Lenses IR LEDs (N9P-4RA2)
Luminys N9 2 x 4MP Unstitched Dome 2.8 mm Lenses IR LEDs (N9P-4RA2)
SKU:N9P-4RA2
Regular price
$777.58
Regular price
Sale price
$777.58
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Not sure this fits your system?Call or text a TechChefs tech at 972-901-9948 or email us the model number. We will confirm before you order.
- Genuine OEM part
- Ships from Texas
- Real tech support
The Luminys N9P-4RA2 is a 2 x 4MP LumiFlex Dual-Sensor Dome Camera built around two 4MP 1/2.7-in. CMOS sensors and 2.8 mm lenses. It is IP67 and IK10 rated, NDAA compliant, and powered by 12 VDC, PoE (802.3af).
- 2 x 4MP Dual-Sensor Dome HousingDual 4MP 1/2.7-in. CMOS sensor, 2688 × 1520 maximum resolution.
- 2.8 mm Fixed Lenses101° horizontal field of view, F1.6 maximum aperture.
- LumiFlexLumiFlex technology delivers the comprehensive, flexible coverage of multiple single-sensor cameras using a single camera housing.
- Video Content AnalyticsLine Crossing, Intrusion
- Intelligent Motion Detection (iMD)Intelligent Motion Detection (iMD) technology accurately detects and filters humans and vehicle in a monitoring area.
- LumiDesertPro and LumiPolarProRated for -40 to 60 °C (-40 to 140 °F) operation.
Key technologies
- LumiFlex
- LumiFlex technology delivers the comprehensive, flexible coverage of multiple single-sensor cameras using a single camera housing. LumiFlex cameras have multiple camera sensors that can be individually positioned to capture different areas of a scene. The footage from each sensor can then be combined to create one continuous stream to reduce the number of licenses required for a higher return on investment.
- Video Content Analytics (VCA)
- Video Content Analytics (VCA) is the umbrella for line crossing and intrusion analytics. Line Crossing identifies when a person or object crosses a defined line. Intrusion detects when a person or object breaches the boundaries of a defined area or enters a restricted area. VCA is available on most Luminys network cameras.
- Intelligent Motion Detection (iMD)
- Intelligent Motion Detection (iMD) technology accurately detects and filters humans and vehicle in a monitoring area. Using an advanced algorithm, iMD can accurately detect humans and vehicles while reducing false alarms caused by other objects, animals, or lighting. Users can be alerted to iMD events for timely security. iMD events can be saved for future reference and easily searched for at a later time for forensic analysis and to assist in investigations.
- LumiPolarPro and LumiDesertPro
- LumiPolarPro and LumiDesertPro technology ensure rugged all-weather performance. Depending on the product model, LumiPolarPro enables dependable performance in -40 °C (-40 °F) or lower, and LumiDesertPro allows operation in temperatures 60 °C (140 °F) or higher.
Specifications
Camera
| Luminys Series | Specialty |
|---|---|
| Image Sensor | Dual 4MP 1/2.7-in. CMOS sensor |
| Maximum Resolution | 2688 × 1520 |
| Minimum Illumination |
Color: 0.0007 Lux at F1.6 0 Lux With IR Illumination On |
| Number of Illuminators | Eight (8) IR LEDs (Four (4) IR LEDs per Sensor) |
| Illuminator Control | Automatic, Manual |
| Maximum Illumination Distance | Up to 30.5 m (100.0 ft) |
| Electronic Shutter Speed | Automatic, Manual 1/3 s to 1/100,000 s |
| S/N Ratio | > 56 dB |
Lens
| Iris Type | Fixed |
|---|---|
| Lens Type | Fixed |
| Focal Length | 2.8 mm |
| Maximum Aperture | F1.6 |
| Field of View |
Horizontal: 101° Vertical: 54° Diagonal: 120° |
| Close Focus Range | 1.1 m (3.6 ft) |
| DORI Distance |
Detect: 63.1 m (207.0 ft) Observe: 25.0 m (82.0 ft) Recognize: 12.5 m (41.0 ft) Identify: 6.3 m (20.7 ft) |
Video
| Compression | H.264, H. 265, Smart Encoding H.265, Smart Encoding H.264, MJPEG (Sub Stream 1 Only) |
|---|---|
| Standard Codec | Supported |
| Stream Capability | Two (2) Streams |
| Resolution | 4MP (2688 x 1520), 4MP (2560 x 1440), 3MP (2048 x 1536/2304 x 1296), 1080p (1920 x 1080), 1.3MP (1280 x 960), 720P (1280 x 720), D (704 x 480), VGA (640 x 480), CIF (352 x 240) |
| Maximum Frame Rate |
Main Stream: 2688 x 1520 at 20 fps Sub Stream 1: D at 30 fps Sub Sream 2: 1080p at 30 fps |
| Video Bit Rate |
H.264: 3 kbps to 10,240 kbps H.265: 3 kbps to 10,240 kbps |
| Bit Rate Control | CBR/VBR |
| Day/Night | Color, Black and White |
| Light Balancing | Wide Dynamic Range (120 dB) |
| Noise Reduction | 3D NR |
| Image Angle | 0°/90°/180°/270° |
| Mirror Rotation | Supported |
| Region of Interest | Four (4) Areas |
| Privacy Masking | Four (4) Areas |
Analytics
| Intelligent Motion Detection | Supported with Alarms for Vehicles and Humans |
|---|---|
| Video Content Analytics | Line Crossing, Intrusion |
Audio
| Compression | G.711a, G.711Mu, PCM |
|---|---|
| Interface |
Input: Built-in Microphone and One (1) Channel Output: One (1) Channel |
Alarm
| Event | Line Crossing, Intrusion, Motion Detection, iMD, Audio Detection, Video Tampering, Disk Full, Disk Error, Offline, IP conflict, Voltage Exception, Security Warning |
|---|---|
| Interface |
Input: One (1) Channel (3V-5VDC, 5 mA) Output: One (1) Channel (12 VDC, 300 mA) |
Network
| Interface | RJ-45 (10/100 Base-T) |
|---|---|
| Protocol | IPv4, IPv6, DNS, TCP, UDP, DHCP, HTTP, HTTPS, 802.1x, RTSP, DDNS, P2P, SMTP, RTMP, PPPoE, UPnP, SNMP, Bonjour, QoS, Auto Registration, ICMP, IGMP, FTP, SFTP, RTP, RTCP, NTP, NFS |
| Interoperability | ONVIF (Profile S/G/T), CGI |
| Browser | Chrome, Firefox, Edge |
| Storage | FTP, SFTP, MicroSD Card (Max. 256 GB), NAS, Local Recording to PC |
Electrical
| Power Supply | 12 VDC, PoE (802.3af) |
|---|---|
| Power Consumption |
Maximum: 13.0 W Standard: 4.8 W |
Construction
| Net Weight | 0.6 kg (1.4 lb) |
|---|---|
| Gross Weight | 0.8 kg (1.8 lb) |
| Operating Temperature | -40 to 60 °C (-40 to 140 °F) |
| Storage Temperature | -40 to 60 °C (-40 to 140 °F) |
| Storage Humidity | < 95% RH (Non-Condensing) |
| Protection Ratings | IP67, IK10 |
| Product Dimensions | 164.0 mm x 84.0 mm x 69.4 mm (6.46 in. x 3.31 in. x 6.7 in.) |
| Packaging Dimensions | 205.0 mm x 121.0 mm x 101.0 mm (8.1 in. x 4.8 in. x 4.0 in.) |
| Material | Metal |
Certifications and Compliance
| Certifications | FCC, IC |
|---|---|
| Compliance | NDAA |
Mounting options
| Ceiling Mount (Low Ceilings) | LUM-E04 |
|---|---|
| Ceiling Mount (High Ceilings) | LUM-E05 |
| Wall Mount | LUM-W09 |
| Junction Box | LUM-J09 |
Download the official N9P-4RA2 datasheet (PDF)
Mounting parts are sold separately unless marked included; every part listed for a mount type is required. Sold, installed and supported by TechChefs, an authorized Luminys dealer (TX Security License B30874201).
