Luminys 4MP Network LumiLuxSmart Black Turret Camera (2.8mm) (N3T-4LA2B)
Luminys 4MP Network LumiLuxSmart Black Turret Camera (2.8mm) (N3T-4LA2B)
SKU:N3T-4LA2B
Regular price
$281.99
Regular price
Sale price
$281.99
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Not sure this fits your system?Call or text a TechChefs tech at 972-901-9948 or email us the model number. We will confirm before you order.
- Genuine OEM part
- Ships from Texas
- Real tech support
The Luminys N3T-4LA2B is a 4MP Network LumiLuxSmart Turret Camera built around a 1/2.9-in. 4MP Progressive CMOS sensor and a 2.8 mm lens. It is IP67 rated, NDAA compliant, and powered by 12 VDC, PoE (802.3af).
- 4MP White or Black Turret Housing1/2.9-in. 4MP Progressive CMOS, 2688 × 1520 maximum resolution.
- 2.8 mm Fixed Lens95° horizontal field of view, F1.6 maximum aperture.
- LumiLuxSmartIR and White-Light LEDs
- Video Content AnalyticsLine Crossing, Intrusion
- Intelligent Motion Detection (iMD)Intelligent Motion Detection (iMD) technology accurately detects and filters humans and vehicle in a monitoring area.
- LumiPolarPro and LumiDesertProRated for -40 to 60 °C (-40 to 140 °F) operation.
Key technologies
- LumiLuxSmart
- LumiLuxSmart technology allows cameras to capture clear, full-color video day or night. When motion is detected, LumiLuxSmart cameras switch from IR LEDs to white-light LEDs to illuminate a scene, then switch back to IR mode once motion has ceased to prevent light pollution and energy inefficiency.
- Intelligent Motion Detection (iMD)
- Intelligent Motion Detection (iMD) technology accurately detects and filters humans and vehicle in a monitoring area. Using an advanced algorithm, iMD can accurately detect humans and vehicles while reducing false alarms caused by other objects, animals, or lighting. Users can be alerted to iMD events for timely security. iMD events can be saved for future reference and easily searched for at a later time for forensic analysis and to assist in investigations.
- Video Content Analytics (VCA)
- Video Content Analytics (VCA) is the umbrella for line crossing and intrusion analytics. Line crossing identifies when a person or object crosses a defined line. Intrusion detects when a person or object breaches the boundaries of a defined area or enters a restricted area. VCA is available on most Luminys network cameras.
- LumiPolarPro and LumiDesertPro
- LumiPolarPro and LumiDesertPro technology ensure rugged all-weather performance. Depending on the product model, LumiPolarPro enables dependable performance in -40 °C (-40 °F) or lower, and LumiDesertPro allows operation in temperatures 60 °C (140 °F) or higher.
Specifications
Camera
| Luminys Series | Starter |
|---|---|
| Image Sensor | 1/2.9-in. 4MP Progressive CMOS |
| Maximum Resolution | 2688 × 1520 |
| Minimum Illumination |
Color: 0.005 Lux at F1.6 Black/White: 0.0005 Lux at F1.6 0 Lux With IR Light On |
| Number of Illuminators | One (1) White-Light LED, One (1) IR LED, Supports LumiLuxSmart |
| Illuminator Control | Automatic, Manual |
| Maximum Illumination Distance |
IR: Up to 30.5 m (100.0 ft) White Light: Up to 30.5 m (100.0 ft) |
| Electronic Shutter Speed | Automatic, Manual 1/3 s to 1/100,000 s |
| Installation Angle |
Pan/Rotation: 0° to 360° Tilt: 0° to 78° |
| S/N Ratio | > 56 dB |
Lens
| Iris Type | Fixed |
|---|---|
| Lens Type | Fixed |
| Focal Length | 2.8 mm |
| Maximum Aperture | F1.6 |
| Field of View |
Horizontal: 95° Vertical: 52° Diagonal: 114° |
| Close Focus Range | 1.1 m (3.6 ft) |
| DORI Distance |
Detect: 63.4 m (208.0 ft) Observe: 25.1 m (82.4 ft) Recognize: 12.4 m (40.7 ft) Identify: 6.2 m (20.3 ft) |
Video
| Compression | Smart Encoding H.265+, H.265, Smart Encoding H.264+, H.264, MJPEG (Sub Stream Only) |
|---|---|
| Standard Codec | Supported |
| Stream Capability | Two (2) |
| Resolution | 4MP (2688 x 1520), 4MP (2560 x 1440), 3MP (2304 x 1296), 1080p (1920 x 1080), 1.3MP (1280 x 960), 720P (1280 x 720), D (704 x 480), VGA (640 x 480), CIF (352 x 240) |
| Maximum Frame Rate |
Main Stream: 2688 x 1520 at 20 fps Sub Stream 1: D at 30 fps |
| Video Bit Rate |
H.264: 3,072 kbps to 6,144 kbps H.265: 1,280 kbps to 6,144 kbps |
| Bit Rate Control | CBR/VBR |
| Day/Night | Automatic (ICR), Color, Black and White |
| Light Balancing | Wide Dynamic Range (120 dB) |
| Noise Reduction | 3D NR |
| Image Angle | 0°/90°/180°/270° |
| Mirror Rotation | Supported |
| Region of Interest | Four (4) Zones |
| Privacy Masking | Four (4) Zones |
Analytics
| Video Content Analytics | Line Crossing, Intrusion |
|---|---|
| Intelligent Motion Detection | Supported with Alarms for Vehicles and Humans |
Audio
| Compression | G.711a, G.711Mu, PCM |
|---|---|
| Interface | Input: Built-in Microphone |
Alarm
| Event | Line Crossing, Intrusion, Motion Detection, iMD, Audio Detection, Video Tampering, Disk Full, Disk Error, Voltage Detection, Security Exception |
|---|
Network
| Interface | RJ-45 (10/100 Base-T) |
|---|---|
| Protocol | IPv4, IPv6, DNS, TCP, UDP, DHCP, HTTP, HTTPS, 802.1X, RTSP, DDNS, P2P, SMTP, RTMP, UPnP, Auto Registration, ICMP, IGMP, FTP, SFTP, RTP, RTCP, ARP, NTP, Multicast, NFS |
| Interoperability | ONVIF (Profile S/G/T), CGI |
| Browser | Chrome, Firefox, Edge |
| Client | LumiViewer, LumiViewer Mobile App |
| Storage | FTP, SFTP, Micro SD Card (Max. 256 GB) |
Electrical
| Power Supply | 12 VDC, PoE (802.3af) |
|---|---|
| Power Consumption |
12 VDC: Maximum 6.6 W, Normal 2.4 W PoE: Maximum 7.9 W, Normal 3.0 W |
Construction
| Net Weight | 0.5 kg (1.2 lb) |
|---|---|
| Gross Weight | 0.7 kg (1.6 lb) |
| Operating Temperature | -40 to 60 °C (-40 to 140 °F) < 95% RH (Non-Condensing) |
| Storage Temperature | -40 to 60 °C (-40 to 140 °F) |
| Protection Ratings | IP67 |
| Product Dimensions | 122.0 mm × 111.8 mm (4.8 in. × 4.4 in.) |
| Packaging Dimensions (L x W x H) | 148.0 mm x 139.0 mm x 137.0 mm (5.3 in. x 5.5 in. x 5.4 in.) |
| Material | Metal |
Certifications and Compliance
| Certifications | FCC, IC |
|---|---|
| Compliance | NDAA |
Mounting options
| Junction Box | LUM-J02 or LUM-CJ11 or LUM-CJ11B |
|---|---|
| Wall Mount | LUM-W01 or LUM-W01B |
| Horizontal Pole Mount (Option 1) | LUM-W01 or LUM-W01B + LUM-P02 |
| Horizontal Pole Mount (Option 2) | LUM-A01 + LUM-W02 + LUM-P01 |
| Vertical Pole Mount | LUM-A01 + LUM-E01 + LUM-P01 |
| Pendant Mount | LUM-A01 + LUM-E01 |
| Corner Mount | LUM-A01 + LUM-W02 + LUM-C01 |
Download the official N3T-4LA2B datasheet (PDF)
Possible match, please check: store has N3T-4LA2 (Active/Archived); this SKU looks like a black color version Sold, installed and supported by TechChefs, an authorized Luminys dealer (TX Security License B30874201).
